Thermo Thermal Grease thermal paste TU 1g

Thermo Thermal Grease thermal paste TU 1g

Description Feature Specification
  • Thermal grease used in CPU and radiator interstitial, high power transistor, SCR components.

    Graphite thermal grease use the hing conductivity of graphite to fit the gap between IC or

    transistor and the heatsink, increase their contact area to achieve the best results.

    All of our products have passed the SGS test and in accordance with ROHS.

    We can provide many kinds of package in order to facilitate our customers choose to use.

    It can be directly pasted or applied through screen printing. Here the recommended pasting thickness is 0.1mm to 0.15mm.
    Following items are recommended for screen printing:
    Apply 80-mesh nylon screen;
    Use hard rubber material with hardness of 70 to produce scraper;
    Keep 1mm to 2mm between screen and pasted surface;
    Keep an angle of 45° between scraper and pasted surface and keep uniform pressure and speed to control the scraper, thus ensuring uniform thickness of thermal grease.

  • 1.Extreme Performance
    Ultra low thermal resistance and superior heat conductance maintain the highest performance level of heat transfer between the heat source and heatsink for maximized cooling performance.
    2.Convenient Application and Storage
    The syringe applicator provides convenience during storage and applicationon a variety of computer components such as the CPU, GPU, and Northbridge chipset.
    3.High Safety Standards
    The composition is dielectric (electrically nonconducting) to prevent electrical hazards and complies with the RoHS
